No. Item Qty
Not shown LCD harness 1 ea
Individual parts
No. Material no. Item Qty
44 103557 VSM 6000 temp blank front 1 ea
45 103562 VSM 6000 thermal shield 1 ea
48 103565 VSM 6000 LCD bezel 1 ea
54 103558 VSM 6000 probe well seal 1 ea
56 103542 VSM 6000 temp front housing 1 ea
55 103543 VSM 6000 horizontal struts 2 ea
53 103545 VSM 6000 temp housing (templess) 1 ea
62 103573 VSM 6000 LCD frame 1 ea
Not shown 103548 VSM 6000 USB mini B to USB A right angle 2 ea
Not shown 103549 VSM 6000 Ethernet cable 1 ea
Not shown 103563 PLFM USB cable mini B RT-type A RT 1 ea
Not shown 103564 PLFM SpO2 blank 1 ea
Not shown 103572 VSM 6000 USB cable separator 1 ea
Not shown 103578 PLFM LCD harness 1 ea
Miscellaneous parts
Serv Kit, VSM6000, Screws and fasteners (material no. 103395)
No.
Item Qty
10 Screw, plastite #4-20 X 0.500 Torx-pan head 160 ea
14 Screw, M4 X 10 pan head with NYLOC 45 ea
29 Bumper, 3M-SJ5012 40 ea
47 Screw, M3 x 5 pan head 60 ea
60 HSG clamp 10 ea
Service manual Field replaceable units 137
