Welch Allyn Connex 6000 Series User Manual

Disassembly and repair reference
Screws and fasteners
The following table lists torque specifications for all screws and fasteners.
Qty Location Type Size/length Torque Bit type
1 Communications door Captive screw #8-32 X 0.656 6.0 inch-pound ±1.0
inch-pound
Slotted or #2
Phillips
8 Main board Pan head machine M3 X 8 6.0 inch-pound ±1.0
inch-pound
#1 Phillips
4 Radio board
2 Battery connector board Plastite #4-20 X 0.500 7.5 inch-pound ±0.5
inch-pound
Torx T10
4 Communications board
2 Ground stud assembly
4 Handle to front housing
6 Horizontal struts to front
housing
2 HSG clamp/temperature
housing
4 Metal chassis to bottom
housing
4 Power-supply cover
2 Printer module to top housing
2 Temperature housing top
1 Temperature module mounting
cover
4 LCD plate M4 shoulder M4 6.0 inch-pound ±1.0
inch-pound
#2 Phillips
168 Appendices Welch Allyn Connex
®
Vital Signs Monitor 6000 Series™
