English | 3 | Machine description
12 | 89014478; 2020-06 | Operating instructions CTR Series
Working direction display
Working direction “left to right” Working direction “right to left”
Start button (4)
The colours have the following meanings:
Colour Meaning
Not lit Warewasher is switched off.
Orange Warewasher is filling and heating up.
Green Warewasher is ready for use.
Blue Warewasher is washing or rack conveyor is active.
Red The warewasher no longer washes because there is a serious error.
Transport speeds (1)
The following transport speeds are available:
Transport speed Soiling of the dishes
Low Severe
Medium Normal
High Light
The transport speed Medium is pre-selected (blue frame) as soon the warewasher is ready.
3.4 Wash modes
The service technician sets the wash mode of the warewasher at commissioning. In addition, he also sets the alternat-
ively selectable wash modes.
The following wash modes are available:
Wash mode Meaning
Hygiene The transport speed decreases if the tank and/or boiler temperature drops. This en-
ables the target temperature to be reached again after a certain time. The transport
speed then increases again.
Speed The transport speed stays constant even if the tank and / or boiler temperature drops.
HighTemp Wash in Hygiene mode but with a higher tank temperature.
Containers Only for warewashers with dual rinse: The first line of dual rinse is switched off. This ex-
tends the drip section between the main and rinse zones for long wash items (e.g.
trays) and improves the rinse result.
The “Containers” wash mode is only available as an alternative wash mode.
The wash mode can be changed during the washing process. (}34).
See also
2 Washing [}32]
