Machine description | 3 | English
Operating instructions CTR Series | 89014478; 2020-06 | 15
3.7 Suction tube with level control
A suction tube is needed to suck out the chemicals from the containers.
– Do not place the suction tube for the rinse aid in the container holding detergent defoamer, or vice versa.
– Use the suction tube only with sufficiently stable containers. Narrow and tall containers can tip as soon as the suction
tube is pulled.
– Do not pull on the dosing hose or main power cable, as this may lead to a defect.
Colour
(cap)
Container
Blue Rinse aid
Grey Detergent
Orange Defoamer
Item Name
1 Float switch for level control
The float switch (1) can detect a defect in the chemicals and indicates this on the display }41.
See also
2 Replace the container [}41]
