3.2 Overview
Figure: CTR M with single rinse and working direction “left to right”
Item Name Item Name
1 Long curtain (length: 520 mm) 6 Short curtain (length: 445 mm)
2 Display 7 Emergency stop switch (optional)
3 Door 8 Strainer
4 Rack bracket 9 Wash arms (top: 5; bottom: 4)
5 Rack conveyor with push bars 10 Filter cassette
Warewashers with dual rinse additionally have a strainer and two wash arms in the rinse zone.
