7 - 40
GS1 DataBar Expanded
< Default All GS1 DataBar Expanded Settings >
GS1 DataBar Expanded On/Off
GS1 DataBar Expanded Message Length
Scan the bar codes below to change
the message length. Ref
er to
Message Length Description
(page 7-2) f
or additional inf
ormation. Mini-
mum and Maximum lengths = 4-74.
Minimu
m Default = 4, Maxim
um
Def
ault = 74.
* On
Off
Minimum Message Length
Maximum Message Length
213
215
