Xerox
®
D70n Scanner Scanner Options, Maintenance and Troubleshooting
10-12 User Guide
Replacing the ADF (Feed) Roller
The roller will wear out and is designed to be a user-replaceable part. A worn roller can cause
documents to feed in skewed at an angle, or multiple pages to feed at the same time. Before
replacing the roller you should clean it as excessive dust on the roller will make it appear worn and
smooth. You cannot properly diagnose a worn roller until you have cleaned it. You should generally
replace the roller every 160,000 to 200,000 scans.
Replacement parts can be purchased from the Supplies & Accessories page for your scanner at
www.xeroxscanners.com
.
1. Open the Automatic Document Feeder cover.
2. Locate the roller cover in the body of the scanner.
3. Move the paper guides to the side and then pull the feed roller cover away from the scanner.
4. Rotate the belt upwards.
To Next Page
