Chapter 1: SP605 Evaluation Board
Table 1-30: Onboard Power System Devices
Device Type
Reference
Designator
Description
Power Rail Net
Name
Power Rail
Voltage (V)
Schematic
Page
UCD9240PFC
(1)
U26 PMBus Controller - Core (Addr = 52) 21
PTD08A010W U18 10A 0.6V - 3.6V Adj. Switching Regulator VCCINT_FPGA 1.20
(3)
22
PTD08A010W U19 10A 0.6V - 3.6V Adj. Switching Regulator VCC2V5_FPGA 2.50 23
PTD08A010W U20 10A 0.6V - 3.6V Adj. Switching Regulator VCCAUX 2.50 24
UCD9240PFC
(2)
U27 PMBus Controller - Core (Addr = 53) 26
PTD08A010W U21 10A 0.6V - 3.6V Adj. Switching Regulator VCC1V5_FPGA 1.50 29
PTD08A010W U22 10A 0.6V - 3.6V Adj. Switching Regulator VCC3V3 3.30 30
TL1963AKTTR U5 1.5A 12V IN, 5.0V OUT Linear Regulator VCC5 5.00 21
TPS74401 U51 3A 1.5V IN, 1.2V OUT Linear Regulator MGT_AVCC 1.20 27
TPS51200DRCT U11
3A DDR3 VTERM Tracking Linear
Regulator
VTTDDR 0.75 31
TPS51200DRCT U11 10 mA Tracking Reference output VTTVREF 0.75 31
TL1963-18DCQR U44 1.5A 2.5V IN, 1.8V OUT Linear Regulator VCC1V8 1.80 31
LT1763CS8 U49
500 mA 5V IN, 3.0V OUT Linear
Regulator
VCC3V0 3.00 31
TPS73633DBVT U10
400 mA 5V IN, 3.30V OUT Linear
Regulator
DVI_VCCA 3.30 17
Notes:
1. See Table 1-31, part 1 (addr 52)
2. See Table 1-31, part 2 (addr 53)
3. V
CCINT
tolerance meets or exceeds the V
CCINT
±5% specification in the Recommended Operating Conditions table in the
Spartan-6 FPGA Data Sheet. [Ref 1]
Table 1-31: Power Rail Specifications (UCD9240 PMBus Controllers at Addresses 52 and 53)
Device Rail #
Rail
Name
Schematic
Rail Name
Vout
(V)
PG On
(V)
PG Off
(V)
On
Delay
(ms)
Rise
(ms)
Off
Delay
Fall
(ms)
Vout
Over
Fault
(V)
Response
Iout
Over
Fault
(A)
Response
Temp
Over
Fault
(°C)
Response
UCD9240
(Addr 52)
1
Rail
#1
VCCINT
_FPGA
1.2 1.14 1.104
010010
1.344
Shut
down
14
Shut
down
80
Shut
down
2
Rail
#2
VCC2V5
_FPGA
2.5 2.375 2.3
2.8
3
Rail
#3
VCCAUX 2.5 2.375 2.3
UCD9240
(Addr 53)
1
Rail
#1
VCC1V5
_FPGA
1.5 1.425 1.38
010010
1.68
Shut
down
13.203
Shut
down
80
Shut
down
2
Rail
#2
VCC3V3 3.3 3.135 3.036 3.696
