Yaesu FT-710 User Manual

43
Parametric Gain
3-Stage Parametric Equalizer Adjustments (Speech Processor: “OFF”)
Center Frequency
PRMTRC EQ1 FREQ (Low) “100” (Hz) - “700” (Hz) / OFF
OFFPRMTRC EQ2 FREQ (Mid) “700” (Hz) - “1500” (Hz) / OFF
PRMTRC EQ3 FREQ (High) “1500” (Hz) - “3200” (Hz) / OFF
Parametric Gain
PRMTRC EQ1 LEVEL (Low) “-20” (dB) - “+10” (dB)
+5PRMTRC EQ2 LEVEL (Mid) “-20” (dB) - “+10” (dB)
PRMTRC EQ3 LEVEL (High) “-20” (dB) - “+10” (dB)
Q (Bandwidth)
PRMTRC EQ1 BWTH (Low) “0” - “10”
10PRMTRC EQ2 BWTH (Mid) “0” - “10”
PRMTRC EQ3 BWTH (High) “0” - “10”
3-Stage Parametric Equalizer Adjustments (AMC or Speech Processor: “ON”)
Center Frequency
P PRMTRC EQ1 FREQ (Low) “100” (Hz) - “700” (Hz) / OFF
OFFP PRMTRC EQ2 FREQ (Mid) “700” (Hz) - “1500” (Hz) / OFF
P PRMTRC EQ3 FREQ (High) “1500” (Hz) - “3200” (Hz) / OFF
Parametric Gain
P PRMTRC EQ1 LEVEL (Low) “-20” (dB) - “+10” (dB)
0P PRMTRC EQ2 LEVEL (Mid) “-20” (dB) - “+10” (dB)
P PRMTRC EQ3 LEVEL (High) “-20” (dB) - “+10” (dB)
Q (Bandwidth)
P PRMTRC EQ1 BWTH (Low) “0” - “10” 2
P PRMTRC EQ2 BWTH (Mid) “0” - “10”
1
P PRMTRC EQ3 BWTH (High) “0” - “10”
Center Frequency: The center frequency of each of the three bands may be adjusted.
Gain: The amount of enhancement (or suppression) within each band may be adjusted.
Q: The bandwidth over which the equalization is applied may be adjusted.

Yaesu FT-710 Specifications

General

Antenna Tuner	Built-in Automatic Antenna Tuner
Weight	4.5 kg
Type	HF/50 MHz Transceiver
Supply Voltage	13.8 V DC ±15%
IF Frequency	24 kHz
Antenna Connector	SO-239
TX Frequency Range	1.8 - 54 MHz
Modes	AM, FM
RF Output Power	100 Watts
Receiver Type	Superheterodyne
Display	4.3-inch Color TFT
Circuit Type	SDR (Software Defined Radio)
Current Consumption	22 A (maximum)
Output Power	5 - 100 Watts (adjustable)
Dimensions	239 x 80 x 247 mm (W x H x D)
