FTA-750/FTA-550 OperATing MAnuAl
7

MIC/SP
Jack
You may connect the supplied
SCU-15
Headset
Adapter Cable or the optional
SSM-10A
Speaker/
Microphone to this jack. To use this jack, you must
rst remove the cover from the transceiver body.
Do not allow the
FTA-750/FTA-550
to get
wet while the cover over the MIC/SP jack is
removed.

DATA
Jack
You may connect the optional USB cable to this
jack. To use this jack, you must rst lift the rubber
cover away from the transceiver body.
Do not allow the
FTA-750/FTA-550
to get
wet while the rubber cover is removed.

EXT DC
Jack
When an external 9.5- to 10.5-Volt DC power
source is available, you may connect the
SDD-12
Cigarette Lighter DC/DC Converter here.
1) Do not allow the
FTA-750/FTA-550
to
get wet while the rubber cover is removed.
2) Do not connect any accessory unap-
proved by YAESU to supply DC power.
controls & connectors
(
rIght sIde
)



DATA
MIC/SP
EXT
DC
PTT
SQL
