Power System
ENGINE SYSTEM
NOTE: Engine availability may be different in your
market. Contact your local Hyster dealer for more
information.
Engine Overview
Refer to Table 2 for the imported DUAL FUEL and
LPG used for 2.0-3.5t forklift trucks in A series.
Table 2. Gasoline Engine (2.4)
Model PSI 4G64-2.4L
Type 4-Stroke, Water-Cooling, Straight-Line, and Valve in Head
Number of Cylinders 4
Cylinder Diameter × Stroke 86.5 × 100 mm (3.41 × 3.94 in.)
Total Displacement I
2.35 liter (143.4 in.
3
)
Compression Ratio 9.5
Rated Power/
Speed kw(ps)/rpm
Gasoline Engine
48/2700（kw/rpm）
64.4/2700（hp/rpm）
LPG Engine
46/2700（kw/rpm）
61.7/2700（hp/rpm）
Max Torque/Speed
Gasoline Engine
170/2400（N.m/rpm）
125.4/2400（lbf·ft/rpm）
LPG Engine
168/1600（N.m/rpm）
123.9/1600（lbf·ft/rpm）
No-Load Min Speed 750 rpm
Fuel Specific Consumption 290 g/psh (.096 g/hph)
Total Length × Total Width × Total
Height
677.4 × 543.6 × 711.0 mm
(26.7 × 21.4 × 28.0 in.)
Movement Direction In Clockwise Direction Looking from the End of Fan
Firing Order 1-3-4-2
8000 YRM 2199 Power System
5
