Table 2. Gasoline Engine (2.4) (Continued)
Model PSI 4G64-2.4L
Valve Timing
Inlet Valve Open
before Top Dead
Center (BTDC)
8°
Inlet Valve Close
after Bottom Dead
Center (ABDC)
48°
Exhaust Valve
Open before
Bottom Dead
Center (BBDC)
31°
Exhaust Valve
Close after Top
Dead Center
(ATDC)
36°
Timing belt change interval 6000 hrs
Cooling System Forced Circulation Water Cooling
Lubricating System Forced Lubrication
Gasoline Pump Membrane Type
Air Filter Paper Element Filter
Engine Oil Pump Gear Type
Oil Rough Filter Paper Filtration
Water Pump Centrifugal Type
Thermostat Wax Type
Generator
Voltage 12V
Current 70A
Starter
Voltage 12V
Output Power 1.2 kW (1.61 hp)
Battery
Voltage 12V
Capacity 60Ah
Referential Data
Lubricating Oil 4.5 liter (4.7 qt)
Coolant
Engine 3.5 liter (3.7 qt)
Radiator 3.5 liter (3.7 qt)
Refer to the engine operation and maintenance
manuals for more information about engines used for
2-3.5t forklift trucks.
Fuel System
Fuel system is composed of fuel tank, fuel quantity
sensor, and fuel quantity indicator. See Figure 5 and
Figure 6.
