Yamaha PSR-A3000 User Manual

PSR-A3000 Owner’s Manual 153
Songs
3
6 Press the SONG [J] (STOP) button (or press the [C] button) to return to the top of the
Song, then hear the newly entered Song by pressing the [
F/ K] (PLAY/PAUSE) button.
7 Press the [EXIT] button to exit from the Step Recording display.
8 Press the [I] (SAVE) button to carry out the Save operation.
For details, refer to page 28.
NOTICE
The recorded Song data will be lost if you select another Song or turn off the power to the instrument without carrying out the Save operation.
[A]/[B]/
[C]
Moves the cursor in the list.
[G] Determines the velocity (loudness) of the note to be entered. The velocity
value can be specified within a range from 1 to 127. The higher the velocity
value, the louder the actual sound.
KBD.VEL: Actual resulting velocity
fff: 127
ff: 111
f: 95
mf: 79
mp: 63
p: 47
pp: 31
ppp: 15
[H] Determines the gate time (actual length) of the note to be entered.
Normal: 80%
Tenuto: 99%
Staccato: 40%
Staccatissimo: 20%
Manual: The gate time can be set to any desired percentage by using the
Data dial.
[I] Determines the note type to be entered: normal, dotted or triplet.
[J] DELETE Deletes the data of the current line.
[1 ] BAR Sets the position of the note to be entered. Note that a quarter note has a res-
olution of 1,920 clocks.
[2 ]BEAT
[3 ]CLOCK
[4 ]–
[8 ]
Determines the note length to be entered: whole-note, half-note, quarter-
note, eighth-note or sixteenth-note.

Yamaha PSR-A3000 Specifications

General

Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black, Grey
Sound effects	Flanger/Digital Signal Processing (DSP), Reverberation
RMS rated power	30 W
Number of speakers	2
Chorus effects quantity	106
Keyboard number of keys	61
Preset programs quantity	4
Maximum polyphony (notes)	128
Display type	LCD
Display diagonal	7 \
Power source type	DC

Weight and Dimensions

Depth	437 mm
Width	1002 mm
Height	148 mm
Weight	11200 g
