PSR-A3000 Owner’s Manual 197
Connections
10
MIDI Transmit Settings
The explanations here apply to the TRANSMIT page in step 4 on page 194. This determines which parts will be
sent as MIDI data and over which MIDI channel the data will be sent.
1 Use the [A]/[B] buttons or [1 ]/[2 ] buttons to select the part for changing
transmit settings.
The Parts listed on this display are the same as those shown in the MIXING CONSOLE display and
CHANNEL ON/OFF display with the exception of the two parts below.
UPPER: A keyboard part played on the right side of the keyboard from the Split Point for the Voices (RIGHT
1 and/or 2).
LOWER: A keyboard part played on the left side of the keyboard from the Split Point for the Voices. This is
not affected by the on/off status of the [ACMP] button.
2 Use the [3 ] buttons to select a channel via which the selected part will be
transmitted.
NOTE If the same transmit channel is assigned to several different parts, the transmitted MIDI messages are merged to a single channel—resulting in unexpected
sounds and possible glitches in the connected MIDI device.
NOTE Protected Songs cannot be transmitted even if the proper Song channels 1–16 are set to be transmitted.
3 Use the [4 ]–[8 ] button to determine the types of data to be sent.
For information on the MIDI messages which can be set here, see “Note Events” on page 166.
1
1 2 3
The dots corresponding to each channel (1–16) flash
briefly whenever any data is transmitted on the chan-
nel(s).
NOTE If “WLAN” is shown, this instrument can handle MIDI
messages received via the USB wireless LAN adaptor
connected to the [USB TO DEVICE] terminal. When
“WLAN” is not shown although the USB wireless LAN
adaptor is connected, turn the instrument off then on
again.
To Next Page
