Yamaha RX-A720 User Manual

APPENDIX ➤ Specifications En 119
Input jacks
• Analog Audio
Audio x 4 (AV 5–6, AUDIO 1–2)
• Digital Audio (Supported frequencies: 32 kHz to 96 kHz)
Optical x 2 (AV 1, AV 4)
Coaxial x 2 (AV 2–3)
•Video
Composite x 5 (AV 3–6, VIDEO [Front Panel])
Component x 2 (AV 1–2)
• HDMI Input
HDMI x 6 (HDMI 1–5, V-AUX)
•Other
USB x 1 [Front Panel] (USB2.0)
USB x 1 [Rear Panel]
(For Yamaha Accessory, Power Supply Only)
NETWORK x 1 (100Base-TX)
Output jacks
• Analog Audio
- Speaker Out x 9 (7 ch) (FRONT L/R, CENTER, SURROUND
L/R, SURROUND BACK L/R
*1
, EXTRA SP L/R
*2
)
*1 Note: Assignment is possible [SURROUND BACK,
BI-AMP (FRONT L/R)]
*2 Note: Assignment is possible [ZONE2, PRESENCE]
- Subwoofer Out x 2 (SUBWOOFER 1–2, mono)
- AV OUT x 1
- AUDIO OUT x 1
- ZONE2 OUT x 1
- Headphone x 1
•Video
MONITOR OUT
- Component x 1
- Composite x 1
AV OUT
- Composite x 1
• HDMI Output
HDMI OUT x 1
Remote jacks
• REMOTE IN x 1
• REMOTE OUT x 1
• TRIGGER OUT x 1
HDMI
• HDMI Specification: Deep Color, “x.v.Color,” Auto Lip Sync,
ARC (Audio Return Channel), 3D, 4K
• Video Format (Repeater Mode)
-VGA
- 480i/60 Hz
- 576i/50 Hz
- 480p/60 Hz
- 576p/50 Hz
- 720p/60 Hz, 50 Hz
- 1080i/60 Hz, 50 Hz
- 1080p/60 Hz, 50 Hz, 24 Hz
- 3840 x 2160p/30 Hz, 25 Hz, 24 Hz
- 4096 x 2160p/24 Hz
• Audio Format
-Dolby TrueHD
- Dolby Digital Plus
- Dolby Digital
- DTS-HD Master Audio
- DTS-HD High Resolution Audio
- DTS Express
-DTS
-DSD 6-ch
- PCM 2-ch to 8-ch (Max. 192 kHz/24-bit)
• Content Protection: HDCP compatible
• Link Function: CEC supported
TUNER
• Analog Tuner
FM/AM x 1 (TUNER)
USB
• Capable of iPod, Mass Storage Class USB Memory
• Current Supply Capacity: 2.1 A
Network
• PC Client Function
• Compatible with DLNA ver. 1.5
• AirPlay supported
• Internet Radio
Compatible Decoding Formats
• Decoding Format
- Dolby TrueHD, Dolby Digital Plus
- Dolby Digital, Dolby Digital EX
- DTS-HD Master Audio, DTS-HD High Resolution Audio,
DTS Express
- DTS, DTS 96/24, DTS-ES Matrix 6.1, DTS-ES Discrete 6.1
- DTS Digital Surround
• Post Decoding Format
- Dolby Pro Logic
- Dolby Pro Logic II Music, Dolby Pro Logic II Movie,
Dolby Pro Logic II Game
- Dolby Pro Logic IIx Music, Dolby Pro Logic IIx Movie, Dolby
Pro Logic IIx Game
- DTS Neo:6 Music, DTS Neo:6 Cinema
