Components
27
F9.9, T9.9
EMU25803
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
EWM00020
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
licensing or approval authority regula-
tions.
1
92
12 14 13 15
10 11
15
2
3
4
5
76
12 13 14
17
16 14
8
ZMU07890
1. Manual starter handle*
2. Choke knob*
3. Flushing device
4. Steering friction adjuster*
5. Tilt lock lever*
6. Tilt support knob*
7. Restraint cable attachment
8. Clamp screw
9. Starter button*
10.Alert indicator
11.Starter button*
12.Engine stop button*
13.Gear shift lever*
14.Throttle friction adjuster*
15.Throttle grip*
16.Power tilt switch*
17.Engine shut-off cord (lanyard)
U6DR30E0.book Page 27 Friday, November 30, 2012 4:27 PM
