Components
32
EMU26013
Choke knob for pull type
To supply the engine with the rich fuel mixture
required to start, pull out this knob.
EMU26074
Manual starter handle
The manual starter handle is used to crank
and start the engine.
EMU26081
Starter button
To start the engine with the electric starter,
push the starter button.
EMU26091
Main switch
The main switch controls the ignition system;
its operation is described below.
● “” (off)
With the main switch in the “ ” (off) posi-
tion, the electrical circuits are off, and the key
can be removed.
● “” (on)
With the main switch in the “ ” (on) position,
the electrical circuits are on, and the key can-
not be removed.
● “” (start)
With the main switch in the “ ” (start) po-
sition, the starter motor turns to start the en-
gine. When the key is released, it returns
automatically to the “ ” (on) position.
1. Choke knob
ZMU07888
U6DR30E0.book Page 32 Friday, November 30, 2012 4:27 PM
