Operation
44
EMU27167
Engine oil
1. Put the outboard motor in an upright po-
sition (not tilted). NOTICE: If the motor
is not level, the oil level indicated on
the dipstick may not be accurate.
[ECM01790]
2. Remove oil dipstick and wipe it clean.
3. Insert the dipstick and remove it again.
Be sure to completely insert the dipstick
into the dipstick guide, otherwise the oil
level measurement will be incorrect.
4. Check the oil level using the dipstick to be
sure the level falls between the upper and
lower marks. Fill with oil if it is below the
lower mark, or drain to the specified level
if it is above the upper mark.
EMU40411
Outboard motor
● Check that the outboard motor is mounted
properly and check the outboard motor
mounting bolts for looseness.
● Check the propeller for damage.
● Check for engine oil leaks.
EMU36493
Flushing device
Check that the flushing device’s garden hose
connector is securely screwed on to the fitting
on the bottom cowling. NOTICE: If the gar-
den hose connector is not properly con-
nected, cooling water can leak out and the
engine can overheat during operation.
[ECM01801]
EMU36955
Install top cowling
1. Be sure that the cowling lock lever is re-
leased.
2. Be sure that the rubber seal is seated all
the way around the top cowling.
1. Oil dipstick
1. Oil dipstick
2. Upper mark
3. Lower mark
1. Fitting
2. Flushing device
