Specifications and requirements
15
EMU40501
Specifications
“(SUS)” indicates that the specification is for
the outboard motor when it is equipped with
a stainless steel propeller.
EMU2821V
Dimension and weight:
Overall length:
920 mm (36.2 in)
Overall width:
548 mm (21.6 in)
Overall height L:
1742 mm (68.6 in)
Overall height X:
VF150A 1869 mm (73.6 in)
Motor transom height L:
516 mm (20.3 in)
Motor transom height X:
VF150A 643 mm (25.3 in)
Dry weight (SUS) L:
223 kg (492 lb)
Dry weight (SUS) X:
VF150A 227 kg (500 lb)
Performance:
Full throttle operating range:
5000–6000 r/min
Rated power:
VF150A 110.3 kW (150 HP)
VF175A 128.7 kW (175 HP)
Idle speed (in neutral):
650–750 r/min
Power unit:
Type:
4-stroke DOHC L4 16 valves
Total displacement:
2785 cm³ (169.9 c.i.)
Bore × stroke:
96.0 × 96.2 mm (3.78 × 3.79 in)
Ignition system:
TCI
Spark plug (NGK):
LFR6A-11
Spark plug gap:
1.0–1.1 mm (0.039–0.043 in)
Steering system:
Remote steering
Starting system:
Electric starter
Starting carburetion system:
Fuel injection
Valve clearance IN (cold engine):
0.17–0.24 mm (0.0067–0.0094 in)
Valve clearance EX (cold engine):
0.31–0.38 mm (0.0122–0.0150 in)
Battery rating (CCA/SAE):
680–1150 A
Battery rating (MCA/ABYC):
770–1370 A
Battery rating (RC/SAE):
160 minutes
Battery rating (CCA/EN):
640–1080 A
Battery rating (20HR/IEC):
80 Ah
Maximum generator output:
50 A
Lower unit:
Gear shift positions:
Forward-neutral-reverse
Gear ratio:
VF150A 2.00 (28/14)
VF175A 1.86 (26/14)
Trim and tilt system:
Power trim and tilt
Propeller mark:
M/T
Fuel and oil:
Recommended fuel:
Mid-grade unleaded gasoline (For North
America), Premium unleaded gasoline
U6EH32E0.book Page 15 Wednesday, November 19, 2014 2:58 PM
