5.4 Noise Filter
5.4.1 Specifications
∗ Also use the following compact AC power supply block-type capacitor (X capacitor).
Compact AC power supply block-type capacitor (X capacitor) model: LDA106M-AA (from Soshin Electric Co., Ltd.)
Refer to 10.2.1 EMC Installation Conditions for the installation location of the capacitor.
Power Regeneration
Converter
Noise Filter
Input
Voltage
Model Model
Rated
Current
(A)
Classification
Rated
Voltage
Leakage
Current
(mA)
Manufacturer
Three-
phase,
200 VAC
CACP-JU15A3 HF3060C-SZC-47EDD 60
Three-phase
three-wire
480
VA C
7
(for 200
VA C ,
60 Hz)
SOSHIN
ELECTRIC
CO., LTD
CACP-JU19A3 HF3080C-SZC-47EDD 80
CACP-JU22A3 HF3100C-SZC-47EDD 100
CACP-JU30A3 HF3150C-SZC-47EDD 150
CACP-JU45A3B
HF3200C-SZC-49EDE
*
200
25
(for 200
VA C ,
60 Hz)
Three-
phase,
400 VAC
CACP-JU15D3 HF3030C-SZC-47DDD 30
Three-phase
three-wire
480
VA C
12
(for 400
VA C ,
50 Hz)
SOSHIN
ELECTRIC
CO., LTD
CACP-JU19D3 HF3040C-SZC-47EDD 40
CACP-JU22D3 HF3050C-SZC-47EDD 50
