YASKAWA UAK series User Manual

2.1 Combinations
2-3
Compatible Devices
2
2.1.3 Power Regeneration Converter, SERVOPACK, and Motor
Some restrictions apply when using combinations of a power regeneration converter, SERVOPACKs, and
motors. Use the information in the following table when determining the combination of devices.
•The total continuous output of motors must be equal to or less than the continuous output capacity of the
power regeneration converter.
*1
•The total output of motors must be less than the instantaneous maximum output capacity of the power
regeneration converter.
*1
•The total continuous rated output capacity of SERVOPACKs
*2
must be equal to or less than the continuous
output capacity of the power regeneration converter
*1
multiplied by 2.5.
•The total number of SERVOPACKs used must be equal to or less than ten (This is not the number of axes.)
•The total number of charge constants of SERVOPACKs
*2
must be equal to or less than the allowable charge
constant of the power regeneration converter.
*1
∗1. The continuous output capacity, the instantaneous maximum output capacity, and the allowable charge constant for
individual models of power regeneration converters are shown in this table.
∗2. The continuous rated capacity and charge constant for individual models of SERVOPACKs is shown in this table.
These are not product specifications. Use this information to calculate to determine whether or not the selected com-
bination of devices complies with the recommended operating conditions described above.
Power Regeneration
Converter Model
Continuous Output Capacity (kW)
Instantaneous
Maximum Output
Capacity
(kW)
Allowable Charge
Constant
Ambient
Tem p er at u re
40°C or less
Ambient
Tem pe ra tu re
40 to 55°C
CACP-JU15A3 11 7.7 37.5 132
CACP-JU19A3 15 10.5 46.3 147
CACP-JU22A3 18.5 12.95 55 162
CACP-JU30A3 22 15.4 75 192
CACP-JU45A3B 37 25.9 112.5 390
CACP-JU15D3 11 7.7 37.5 33
CACP-JU19D3 15 10.5 46.3 37
CACP-JU22D3 18.5 12.95 55 41
SERVOPACK Model
Continuous Rated
Capacity
(kW)
Charge Constant
CACR-JUM23ACA 310
CACR-JUM24ACA 414
CACR-JUM25ACA 620
CACR-JU028ACA 3.7 16
CACR-JU036ACA 5.5 24
CACR-JU065ACA 11 40
CACR-JU084ACA 15 52
CACR-JU102ACA 18.5 64
CACR-JU125ACA 22 64
CACR-JU196ACA 37 102
CACR-JUM23DCA 34
CACR-JUM24DCA 44
CACR-JUM25DCA 65
CACR-JU014DCA 3.7 4
CACR-JU018DCA 5.5 6
CACR-JU033DCA 11 10
CACR-JU042DCA 15 13
CACR-JU051DCA 18.5 16
