5 Peripheral Devices
5.5.1 Specifications
5-16
5.5 Base Mounting Units
When mounting servo drivers to bases, use the following base mounting units.
5.5.1 Specifications
Note: The input current that is given above is the current for one base mounting unit.
5.5.2 Power Regeneration Converter and SERVOPACK Combinations
(1) Power Regeneration Converter
(2) SERVOPACK
 SERVOPACK for One Axis
Model
Unit Width
(mm)
Cooling Fan Ter mi na l Bl oc k
Input
Voltage
(VDC)
Input
Current
(A)
Ter mi na l
Screw
Wire Sizes
(AWG)
Tightening
Tor qu e
(Nxm)
JUSP-JUBM050AA 50
24
0.42
M3.5 24 to 12
0.8 to 1.2
Nxm
(7.1 to 10.6
lbfxin)
JUSP-JUBM075AA 75 0.94
JUSP-JUBM100AA 100 0.94
JUSP-JUBM150AA 150 1.88
Power Regeneration Converter Base Mounting Unit
Input Voltage Model Model
Three-phase 200 VAC
CACP-JU15A3
JUSP-JUBM100AACACP-JU19A3
CACP-JU22A3
CACP-JU30A3 JUSP-JUBM150AA
Three-phase 400 VAC
CACP-JU15D3
JUSP-JUBM100AACACP-JU19D3
CACP-JU22D3
SERVOPACK Base Mounting Unit
Input Voltage Model Model
270 VDC
CACR-JU028ACA
JUSP-JUBM050AA
CACR-JU036ACA
CACR-JU065ACA JUSP-JUBM075AA
CACR-JU084ACA
JUSP-JUBM150AACACR-JU102ACA
CACR-JU125ACA
540 VDC
CACR-JU014DCA
JUSP-JUBM050AA
CACR-JU018DCA
CACR-JU033DCA JUSP-JUBM075AA
CACR-JU042DCA
JUSP-JUBM150AA
CACR-JU051DCA
