Yealink T54W User Manual

MetroNet -Yealink Desk Phones T54W & T57W User Guide
Version 1.0
10.25.2021
93
quickly identify callers according to the ring tones.
Procedure
1. Select Directory or navigate to Menu > Directory > Local Director y.
• On the T57W phones, select Director y or navigate to Menu > Directory.
2. Select the desired contact group or All Contacts.
3. Highlight the desired contact and select Option > Detail.
4. Select the desired ring tone from the Ring field.
If Auto is selected, the contact uses the ring tone according to the default priority.
5. Select Save.
7.3 Disabling the Key Tone
If you disable the key tone, the phone will not produce a sound when pressing the keypad keys.
Procedure
1. Navigate to Menu > Basic > Sound > Key Tone.
2. Turn off Key Tone.
3. Select Save.
8 BLUETOOTH
When the Bluetooth mode is activated, you can pair and connect your Bluetooth device to the
phone.
You can scan and pair up to 60 Bluetooth devices with your phone. However, up to two devices
can be connected at a time. If you connect your Bluetooth-enabled mobile phone to the T54W
or T57W phone, you can synchronize the mobile contacts to the phone.
8.1 Activating the Bluetooth Mode
You should activate the Bluetooth mode first when you need to connect the Bluetooth device to
your phone.
Procedure
1. Navigate to Menu > Basic > Bluetooth.
2. Select On from the Bluetooth field.
3. Select Save.
The phone scans the available Bluetooth devices automatically.
8.2 Pairing and Connecting the Bluetooth Headset
When you need the Bluetooth headset to handle calls, you should pair and connect it to your
phone in advance.
