Using the VC110 Video Conferencing Endpoint
101
For example, if you select , the video layout will be shown as below.
Dual Screen
The VC110 has two display ports. When connecting only one display device to the VC110
all-in-one unit, Display1 port is the only available port. To make it easier for users to view video
images, users can connect two display devices to Display1 and Display2 ports respectively.
When two display devices are connected to the VC110 all-in-one unit, the status bar of the
primary display device will display icon.
Two display devices (dual screen) are connected to the VC110 all-in-one unit:
When the endpoint is idle and does not start a presentation.
In the primary display device, the local video image is shown in full size.
In the secondary display device, the local video image is shown in full size (no menu and
status bar).
Primary display device Secondary display device
When the endpoint is idle and starts a presentation.
In the primary display device, the local video image is shown in full size.
In the secondary display device, the presentation is shown in full size (no menu and status
