YOKOGAWA digitalYEWFLO Series User Manual

<APPENDIX 7. LINK MASTER FUNCTIONS>
A7-4
IM 01F06F00-01EN
A7.5 LM Parameters
A7.5.1 LM Parameter List
The tables below show LM parameters of a digitalYEWFLO.
Meanings of Access column entries: RW = read/write possible; R = read only
Index
(SM)
Parameter Name
Sub-parameter Name
(Sub Index)
Default Factory
Setting
Access Remarks
362 DLME_LINK_MASTER_CAPABILITIES_VARIABLE 0x04 RW
363 DLME_LINK_
MASTER_ INFO_
RECORD
0 RW
1 MaxSchedulingOverhead 0
2 DefMinTokenDelegTime 100
3 DefTokenHoldTime 300
4 TargetTokenRotTime 4096
5 LinkMaintTokHoldTime 400
6 TimeDistributionPeriod 5000
7 MaximumInactivityToClaimLasDelay 8
8 LasDatabaseStatusSpduDistributionPeriod 6000
364 PRIMARY_LINK_MASTER_FLAG_VARIABLE – RW LAS: True = 0xFF
non-LAS: False = 0x00
365 LIVE_LIST_STATUS_ARRAY_VARIABLE – R
366 MAX_TOKEN_HOLD_
TIME_ARRAY
0 RW
1 Element1 0x0000×16, 0x012c×16
2 Element2 0x012c×5, 0x0000×27
3 Element3 0x0000×32
4 Element4 0x0000×32
5 Element5 0x0000×32
6 Element6 0x0000×32
7 Element7 0x0000×31, 0x012c×1
8 Element8 0x012c×32
367 BOOT_OPERAT_FUNCTIONAL_CLASS Specied at the time of
order
RW 0x01 (Standard); 0x02
(LM)
368 CURRENT_LINK_
SETTING_RECORD
0 R Settings for LAS
1 SlotTime
2 PerDlpduPhlOverhead
3 MaxResponseDelay
4 FirstUnpolledNodeId
5 ThisLink
6 MinInterPduDelay
7 NumConseeUnpolledNodeId
8 PreambleExtension
9 PostTransGapExtension
10 MaxInterChanSignalSkew
11 TimeSyncClass
369 CONFIGURED_LINK_
SETTING_RECORD
0 4095 RW
1 SlotTime 4
2 PerDlpduPhlOverhead 5
3 MaxResponseDelay 37
4 FirstUnpolledNodeId 0
5 ThisLink 12
6 MinInterPduDelay 186
7 NumConseeUnpolledNodeId 2
8 PreambleExtension 1
9 PostTransGapExtension 0
10 MaxInterChanSignalSkew 4
11 TimeSyncClass
