<APPENDIX 1. LIST OF PARAMETERS FOR EACH BLOCK OF digitalYEWFLO>
A1-6
IM 01F06F00-01EN
A1.3 Transducer Block
Relative
Index
Index Parameter Name Factory Default
Write
Mode
Explanation
0 2000 Block Header TAG: "TB" Block Tag
= O/S
Information on this block such as Block Tag, DD Revision,
Execution Time etc.
1 2001 ST_REV — — The revision level of the static data associated with the
function block. The revision value will be incremented each
time a static parameter value in the block is changed.
2 2002 TAG_DESC (Spaces) AUTO The user description of the intended application of the
block
3 2003 STRATEGY 1 AUTO The strategy eld can be used to identify grouping of
blocks. This data is not checked or processed by the block.
4 2004 ALERT_KEY 1 AUTO The identication number of the plant unit. This information
may be used in the host for sorting alarms, etc.
5 2005 MODE_BLK AUTO AUTO The actual, target, permitted, and normal modes of the
block.
6 2006 BLOCK_ERR 0 — This parameter reects the error status. The factors of
digitalYEWFLO TR Block are;
*Error of TB block.
*TR block is on O/S mode.
7 2007 UPDATE_EVT — — This alert is generated by any change to the static data.
8 2008 BLOCK_ALM — — The block alarm is used for all conguration, hardware,
connection failure or system problems in the block. The
cause of the alert is entered in the subcode eld. The
rst alert to become active will set the Active status in the
Status attribute.
9 2009 TRANSDUCER_
DIRECTORY
1, 2010 — A directory that species the number and starting indices
of the device.
10 2010 TRANSDUCER_
TYPE
Standard Flow with
Calibration (104)
— Identies the device type, which is “Standard Flow with
Calibration” for the digitalYEWFLO.
11 2011 XD_ERROR 0 (No Error) — Indicates the error code of the error of the highest priority
from among the errors currently occurring in the transducer
block.
12 2012 COLLECTION_
DIRECTORY
3, 2013, 0x80020380
2028, 0x80020382,
2031, 0x30003
— A directory that species the number, starting indices, and
DD Item IDs of the data collections in each transducer
within a transducer block.
13 2013 PRIMARY_ VALUE_
TYPE
Volumetric ow (101) O/S The type of measurement represented by the primary
value.
Followings are available for the digitalYEWFLO:
100=mass ow, 101=volumetric ow
14 2014 PRIMARY_ VALUE — — Indicates the ow rate.
15 2015 PRIMARY_ VALUE_
RANGE
(Note 1) — Indicates the ow range.
These values are converted the values of SENSOR_
RANGE by the unit of XD_SCALE and the data of LINE_
SIZE.
16 2016 CAL_POINT_HI Max. range (Note 2) O/S The highest calibrated value. To set within the range of
SENSOR_RANGE.
17 2017 CAL_POINT_LO Min. range (Note 3) O/S The lowest calibrated value. To set within the range of
SENSOR_RANGE.
18 2018 CAL_MIN_SPAN (Note 1) — The minimum calibration span value allowed.
19 2019 CAL_UNIT m
3
/h (1349) (Note 4) O/S The engineering unit for the calibrated values. Read Table
6.2 for the unit available.
20 2020 SENSOR_TYPE Vortex (112) — Indicates the sensor type, which is “Vortex” for the
digitalYEWFLO.
21 2021 SENSOR _RANGE (Note 1) — The high and low range limit values, engineering units
code and the number of digits to the right of the decimal
point for the sensor.
22 2022 SENSOR_SN Serial No. — Serial number.
23 2023 SENSOR_CAL
_METHOD
volumetric (100) O/S The method of the last sensor calibration.
100=volumetric
101=static weight
24 2024 SENSOR_CAL _LOC — O/S Sets/indicates the location of the last sensor calibration.
25 2025 SENSOR_CAL
_DATE
— O/S Sets/indicates the date of the last sensor calibration.
