<5. CONFIGURATION>
5-5
IM 01F06F00-01EN
Table 5.4 VCR Static Entry
Sub-
index
Parameter Description
1 FasArTypeAndRole Indicates the type and role of
communication (VCR). The
following 4 types are used for
the digitalYEWFLO.
0x32: Server (Responds to
requests from host.)
0x44: Source (Transmits
alarm or trend.)
0x66: Publisher (Sends AI,
DI block output to other
blocks.)
0x76: Subscriber (Receives
output of other blocks by
PID block.)
2 FasDllLocalAddr Sets the local address
to specify a VCR in the
digitalYEWFLO. A range of 20
to F7 in hexadecimal.
3 FasDllCongured
RemoteAddr
Sets the node address of the
called party for communication
and the address (DLSAP or
DLCEP) used to specify VCR
in that address. For DLSAP
or DLCEP, a range of 20 to
F7 in hexadecimal is used.
Addresses in Subindex 2 and
3 need to be set to the same
contents of the VCR as the
called party (local and remote
are reversed).
4 FasDllSDAP Species the quality of
communication. Usually, one
of the following types is set.
0x2B: Server
0x01: Source (Alert)
0x03: Source (Trend)
0x91: Publisher/Subscriber
5 FasDllMaxConrm
DelayOnConnect
To establish connection for
communication, a maximum
wait time for the called party’s
response is set in ms. Typical
value is 60 seconds (60000).
6 FasDllMaxConrm
DelayOnData
For request of data, a
maximum wait time for the
called party’s response is
set in ms. Typical value is
60 secounds (60000).
7 FasDllMaxDlsduSize Species maximum DL
Service Data unit Size
(DLSDU). Set 256 for Server
and Trend VCR, and 64 for
other VCRs.
8 FasDllResidual
ActivitySupported
Species whether connection
is monitored. Set TRUE (0xff)
for Server. This parameter
is not used for other
communication.
9 FasDllTimelinessClass Not used for the
digitalYEWFLO.
10 FasDllPublisherTime
WindowSize
Not used for the
digitalYEWFLO.
11 FasDllPublisher
SynchronizaingDlcep
Not used for the
digitalYEWFLO.
12 FasDllSubscriberTime
WindowSize
Not used for the
digitalYEWFLO.
13 FasDllSubscriber
SynchronizationDlcep
Not used for the
digitalYEWFLO.
Sub-
index
Parameter Description
14 FmsVfdId Sets VFD for the
digitalYEWFLO to be used.
0x1: System/network
management VFD
0x1234: Function block
VFD
15 FmsMaxOutstanding
ServiceCalling
Set 0 to Server. It is not used
for other applications.
16 FmsMaxOutstanding
ServiceCalled
Set 1 to Server. It is not used
for other applications.
17 FmsFeatures
Supported
Indicates the type of services
in the application layer. In
the digitalYEWFLO, it is
automatically set according to
specic applications.
These 33 VCRs are factory-set as shown in Table
5.5.
Table 5.5 VCR List
Index
(SM)
VCR
Number
Factory Setting
293 1 For system management (Fixed)
294 2 Server (LocalAddr = 0xF3)
295 3 Server (LocalAddr = 0xF4)
296 4 Server (LocalAddr = 0xF7)
297 5 Trend Source (LocalAddr = 0x07,
Remote Address=0x111)
298 6 Publisher (LocalAddr = 0x20)
299 7 Alert Source (LocalAddr = 0x07,
Remote Address=0x110)
300 8 Server (LocalAddr = 0xF9)
301 to 325 9 to 33 Not set
5.5.2 Function Block Execution Control
According to the instructions given in Section 5.3
“Function Block Link Denitions”, set the execution
cycle of the function blocks and schedule of
execution.
