YOKOGAWA digitalYEWFLO Series User Manual

<10. EXPLOSION PROTECTED TYPE INSTRUMENT>
10-9
IM 01F06F00-01EN
10.3 IECEx
WARNING
• Only trained persons use this instrument in
industrial locations.
• A modication of the equipment would
no longer comply with the construction
described in the certicate documentation.
(1) Technical Data
•Flameproof
Applicable Standard : IEC 60079-0:2011
IEC 60079-1:2014
Certicate : IECEx DEK 11.0077X
Type of Protection:
Ex db IIC T6…T1 Gb (Integral Type and Remote
Type Detector)
Ex db IIC T6 Gb (Remote Type Convertor)
Specication of Protection:
Temperature Class: (Integral Type and Remote
Type Detector)
Temperature Class Process Temperature
T6 -40°C to +80°C
T5 -40°C to +100°C
T4 -40°C to +135°C
T3 -40°C to +200°C
T2 -40°C to +300°C
T1 -40°C to +450°C
*1 Note: Use /HT version above +250°C
Temperature Class: T6 (Remote Type Convertor)
Ambient Temperature:
–30 to +60°C (With indicator)
–40 to +60°C (Without indicator)
Power Supply: 9 to 32Vdc max.
Specicconditionsofuse
• Electrostatic charges on the non-metallic parts
(excluding glass parts) or coated parts of the
equipment shall be avoided.
• The ameproof joints differ from the standard
values in IEC 60079-1. Only personnel authorized
by the manufacturer of the equipment can repair
the ameproof joints.
• The property class of the fasteners used to
fasten the sensor assembly part the transmitter
enclosure is at least A2-50.
•IntrinsicallySafe
Applicable Standard: IEC 60079-0:2011
IEC 60079-11:2011
Certicate: IECEx DEK 15.0012X
Type of Protection:
Ex ia IIC T4...T1 Ga (Integral Type)
Ex ia IIC T6...T1 Ga (Remote Type Detector)
Ex ia IIC T4 Ga (Remote Type Converter)
Ambient Temperature:
-40 to +60°C (Integral Type)
-50 to +80[+78]°C (Remote Type Detector)
-40 to +80°C (Remote Type Converter)
(Option /LT below -29°C, [ ] for Option /MV at T6)
Connect sensor circuit of DYA and DY-N (/HT)
Electrical Data:
Entity Ui = 24 V, Ii = 250 mA, Pi = 1.2 W,
Ci = 3.52 nF, Li = 0 mH
FISCO (IIC) Ui = 17.5 V, Ii = 500 mA, Pi = 5.5 W,
Ci = 3.52 nF, Li = 0 mH
Temperature Class:
(Integral Type)
Temperature Class Process Temperature
T4 ≤ +135°C
T3 ≤ +200°C
T2 ≤ +250°C
T1 ≤ +250°C
(Remote Type Detector)
Temperature Class Process Temperature*
T6 ≤ +84/[+78]°C
T5 ≤ +100°C
T4 ≤ +135°C
T3 ≤ +199°C
T2 ≤ +299/[+288]°C
T1 ≤ +449/[+438]°C
*: Use /HT option above +250 °C, use /LT option below -29 °C, [ ]
for /MV option.
Electrical Connection: ANSI 1/2 NPT female,
ISO M20 X 1.5 female
Specicconditionsofuse
• Electrostatic charges on the non-metallic parts
(excluding glass parts) or coated parts of the
equipment shall be avoided.
• When the enclosure of the ow meter or the
ow converter are made of aluminum, if it is
mounted in an area where the use of EPL Ga
equipment is required, it must be installed such
that, even in the event of rare incidents, ignition
sources due to impact and friction sparks are
excluded.
• The dielectric strength of at least 500 V a.c.
r.m.s. between the intrinsically safe circuits and
the enclosure of the ow meter or the converter
is limited only by the overvoltage protection.
