<13. COMMISSIONING OF DO (Dissolved Oxygen)>
13-2
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
Table 13.1 Menu Structure and Default Values in “Commissioning
Parameter Ref. sect.
Sensor setup Sensor type 13.1
Measurement setup Congure sensor
Unit 13.2.1
Sensor sensitivity
Polarization Voltage
Temperature settings
Temp. element 13.2.2
Temp. compensation 13.2.3
Salinity compensation 13.2.4
Pressure comp. (Measure) 13.2.5
Calibration settings 13.2.6
Sensor diag. settings 13.2.7
Output setup mA 13.3
Output
Process parameter
Setup
Linear
0 % value
100 % value
Table
Burn
Damping time
Simulate Simulation perc.
Congure Hold
Error conguration 13.4
Logbook conguration 13.5
Advanced setup Settings 13.6.1
Tag 13.6.2
Passwords 13.6.3
Date/Time 13.6.4
Communication 13.6.5
HART
PH201G
Factory setup 13.6.6
Display setup Main display (Dual display, Individual display) 13.7.1
Trend 13.7.2
Auto Return 13.7.3
Adjust contrast 13.7.4
MONITOR display 13.7.5
Calculated data setup Function 13.8
NOTE
All the parameters for the quick setup (underlined ones in Table 13.1) are crucial for
measurement. If you change any of them, other parameters may be initialized. For the
parameters that may initialize other values, see Appendix 4.
13.1 Sensor setup
Select the sensor type that is used from among “Galvanic” and “Polarographic.”
The sensor type suitable for the actually connected sensor should be selected.
