AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual Page – 139/155
13 APPENDICES
The goal of this chapter is to give to the operator a general overview relating the
use of Zapi PC CAN Console and Zapi Smart Console.
The description contained in the next paragraph focuses on the basic information
about the connection and change of parameters.
For additional functionalities available for both tools it is suggested to contact
Zapi technicians in order to receive more detailed information or dedicated
documentation.
13.1 Appendix A: PC CAN Console user guide
Windows Pc CAN Console uses standard Zapi communication protocol to display
inverter’s information. It provides all standard Zapi Console functions with the
easier handling of Windows devices. Besides, Pc CAN Console offers another
function: the possibility to save parameter configurations to a file and to restore
them to the control.
Before running Pc CAN Console, the user must install it launching "setup.exe".
13.1.1 PC CAN Console configuration
Running the PC Can Console software, the following window will appear:
the first step to accomplish is to define the CAN device attached to the PC, so
select the “Configuration” (Alt-C) -> Can Device (Ctrl-C) menu or click on Can
Device icon.
