Zapi ACE0 2mC User Manual

AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual Page – 85/155
8.3.2 TESTER – Supervisor microcontroller
The following table lists the supervisor microcontroller data that can be monitored
through the TESTER function.
TESTER (Supervisor µC)
Parameter
Unit of measure
(resolution)
Description
MEASURED SPEED
(A)
Hertz (0.1 Hz) Motor speed measured through the encoder and
expressed in the same unit of FREQUENCY (Hz).
DI0-A1
(A)
OFF/ON Status of the digital input 0 (pin A1).
DI1-A7
(A)
OFF/ON Status of the digital input 1 (pin A7).
DI2-A6
(A)
OFF/ON Status of the digital input 2 (pin A6).
DI3-A32
(A)
OFF/ON Status of the digital input 3 (pin A32).
DI4-A31
(A)
OFF/ON Status of the digital input 4 (pin A31).
DI5-A19
(A)
OFF/ON Status of the digital input 5 (pin A19).
DI6-A20
(A)
OFF/ON Status of the digital input 6 (pin A20).
DI7-A35
(A)
OFF/ON Status of the digital input 7 (pin A35).
DI8-A17
(A)
OFF/ON Status of the digital input 8 (pin A17).
DI9-A29
(A)
OFF/ON Status of the digital input 9 (pin A29).
DI10-A16
(A)
OFF/ON Status of the digital input 10 (pin A16).
DI11-A18
(Not for BLE0)
(A)
OFF/ON Status of the digital input 11 (pin A18).
DI12-A21
(Not for BLE0)
(A)
OFF/ON Status of the digital input 12 (pin A21).
