AFFZP0BB – ACE3 – User Manual Page – 89/139
Error code Effect Condition
Restart
procedure
CAN
OPEN
CODE
MDI
CODE
ZAPI
CODE
LED
CODE
VDC LINK OVERV.
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Stand-by, running
Valves or
Traction/Pump
Request
0XFFCA 77 202 77
valves stopped Request
WRONG ENC SET
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up Key re-cycle 0xFF51 83 181 83
ANALOG INPUT
MC is opened,
EB is applied,
traction/pump stopped
Stand-by, running Key re-cycle 0xFFFA 96 237 96
CTRAP THRESHOLD
MC is opened (the
command is released), EB
is applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
0xFFEB 99 235 99
AUX BATT. SHORT
MC is opened,
EB is applied,
traction/pump stopped
Running
Key re-cycle
0x5001 27 194
27
POS. EB. SHORTED
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up Key re-cycle 0x3223 84 195 84
VDC OFF SHORTED
MC is opened,
EB is applied,
traction/pump stopped
Start-up, stand-by,
running
Key re-cycle
0xFFC8 88 200
88
VKEY OFF SHORTED
MC is opened,
EB is applied,
traction/pump stopped
Start-up, stand-by,
running
Key re-cycle 0x5101 20 220 20
POWERMOS
SHORTED
MC is opened,
EB is applied,
traction/pump stopped
Start-up Key re-cycle 0xFFE9 89 233 89
BUMPER STOP
MC is opened,
EB is applied,
traction/pump stopped
Stand-by, running
Valves or
Traction/Pump
Request
0xFFA2 0 162 0
WRONG SET KEY
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up, stand-by,
running
Key re-cycle
0x3101 41 170 41
WRONG SET
BATTERY
MC is not closed,
EB is applied,
Traction/Pump, valves
stopped
Start-up, stand-by,
running
Key re-cycle 0x3100 41 251 41
