OCR Programming

275

Inverse OCR

Parameter # 856 (SSI # F2h 58h)

Inverse OCR is white or light words on a black or dark background. Select an option for decoding inverse OCR:

• Regular Only - decode regular OCR (black on white) strings only.

• Inverse Only - decode inverse OCR (white on black) strings only.

• Autodiscriminate - decodes both regular and inverse OCR strings.

*Regular Only

(0)

Inverse Only

(1)

Autodiscriminate

(2)
