20
ACQUAINTANCE WITH TRACTOR
C122 C123 C124
REAR WINDOW
Rear window is equipped with handle
and is kept in the open position by gas
struts.
We recommend to latch the win-
dow in closed position when driv-
ing on uneven terrain - danger of
window cracking. Before starting
work with machines implemented
in the rear three point hitch be
sure that the interference be-
tween hitched implement and
opened rear window is avoided at
the maximum lifting of the rear
three point hitch. In case of inter-
ference we recommend to work
with closed window.
SIDE WINDOW
A plastic latch locks the side window in
half-opened position.
TILTABLE ROOF LID
The tiltable roof lid can be opened by
turning the arresting lever and by half-
opening.
Tractor total height is increased
when opened lid. Therefore al-
ways close the lid when passing
through low profiles or when
parking there.
