Parameters 153
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows.
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. Scaling: 1 = 100. 2
Torque Scaling is defined by parameter 46.03 Torque scaling.3
Speed Scaling is defined by parameter 99.09 Motor nominal speed.4
Frequency Scaling is defined by parameter 99.08 Motor nominal
frequency.
5
58.29 EFB act2 type Not applicable
58.31 EFB act1
transparent source
Selects the source of actual value 1 when parameter 58.28
EFB act1 type is set to Transparent.
Note: Applicable only when 79.40 MPPT reference is
disabled. If parameter MPPT reference is enabled, then the
parameter should be set to it’s default value.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page 64). -
58.32 EFB act2
transparent source
Not applicable
58.33 Addressing mode Defines the mapping between parameters and holding
registers in the 400101…465535 Modbus register range.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
Mode 0
Mode 0 16-bit values (groups 1…99, indexes 1…99)
:
Register address = 400000 + 100 × parameter group +
parameter index.
32-bit values (groups 1…99, indexes 1…99)
:
Register address = 420000 + 200 × parameter group +
2 × parameter index.
0
Mode 1 16-bit values (groups 1…255, indexes 1…255)
:
Register address = 400000 + 256 × parameter group +
parameter index.
1
Mode 2 32-bit values (groups 1…127, indexes 1…255)
:
Register address = 400000 + 512 × parameter group +
2 × parameter index.
2
58.34 Word order Selects in which order 16-bit registers of 32-bit parameters
are transferred.
For each register, the first byte contains the high order byte
and the second byte contains the low order byte.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
LO-HI
HI-LO The first register contains the high order word, the second
contains the low order word.
0
LO-HI The first register contains the low order word, the second
contains the high order word.
1
No. Name/Value Description Def/FbEq16
Motor control mode
(see par. 99.04)
Actual 1 type
Speed control Speed
Frequency control Frequency
ACQ80 FW.book Page 153 Thursday, February 14, 2019 11:33 AM
