45
Group 01: Operating Data
Actual Signals monitor ACS140 functions. They do not affect the
performance of the ACS140. Actual Signal values are measured or
calculated by the drive and they cannot be set by the user.
Code Description
0102 SPEED
Displays the calculated speed of the motor (rpm).
0103 OUTPUT FREQ
Displays the frequency (Hz) applied to the motor. (Also shown in OUTPUT
display.)
0104 CURRENT
Displays the motor current, as measured by the ACS140.
(The same value that is shown by the OUTPUT display mode.)
0105 TORQUE
Output torque. Calculated value of torque on motor shaft in % of motor nominal
torque.
0106 POWER
Displays the measured motor power in kW.
Note! ACS100-PAN will not display the unit (“kW”).
0107 DC BUS VOLTAGE
Displays the DC bus voltage, as measured by the ACS140. The voltage is
displayed in Volts DC.
0109 OUTPUT VOLTAGE
Displays the voltage applied to the motor.
0110 ACS 140 TEMP
Displays the temperature of the ACS140 heatsink in degrees centigrade.
0111 EXT REF 1
Displays the selected Hz reference that the reference selection block forwards
to the ramp generator.
0112 EXT REF 2
As parameter 0111 scaled to per cent (%), except when PID controller is on,
then the PID setpoint controller is displayed.
0113 CTRL LOCATION
Displays the active control location. Alternatives are:
0 =
LOCAL
1 = EXT1
2 =
EXT2
See APPENDIX for description of different control locations.
0114 RUN TIME
Shows the total running time of the ACS140 in thousands of hours (kh).
0115 kWh COUNTER
Counts the kilowatt hours of ACS140 in operation.
0116 APPL BLK OUTPUT
The reference value in per cent received from the application block (PID control
block). This value has significance only when the PID Control macro is used.
0117 DI1-DI4 STATUS
Status of the four digital inputs. If the input is activated, the display will indicate
1. If the input is deactivated, the display will be 0.
0118 AI1
Relative value of analogue Input 1 displayed in %.
0119 AI2
Relative value of analogue input 2 displayed in %.
DI 1DI 2DI 3DI 4
