ABB ACS800-04 User Manual

The ACS800-04/U4 and ACS800-04M
19
Type code for ACS800-04M non-pre-assembled units (delivered as kits)
Selection Alternatives
Product series ACS800 product series
Type 04M Drive module. When no options are selected: 6-pulse diode input bridge, IP 00, top
entry, RDCU drive control unit, Standard Control Program, boards without coating,
one set of manuals. No pedestal, no output busbars, no control panel, no EMC filter.
Delivered as kits.
Size Refer to Technical data: IEC ratings in Hardware Manual [3AFE64671006 (English)].
Voltage range
(nominal rating in bold)
2 208/220/230/240 VAC
3380/400/415 VAC
5 380/400/415/440/460/480/500 VAC
7 525/575/600/690 VAC
+ options
Shrouds B060 Frame size R7:
clear plastic shrouds for bottom exit kit (+H352) and input terminals.
Frame size R8:
clear plastic shrouds for vertical busbars and input terminals in
bookshelf mounting (+H354)
Resistor braking D150 brake chopper
Filter E202 EMC/RFI filter for first environment TN (grounded) system, restricted (the A limits)
E210 EMC/RFI filter for second environment TN/IT (grounded/ungrounded) system
E208 common mode filter
Pedestal and output
busbars
H352 bottom exit kit for frame size R7
H354 pedestal with output on the long side (bookshelf)
H355 vertical busbars and support brackets for AC output connection
H356 pedestal (and adapter with +H360) busbar kit for brake resistor and DC connection
H360 pedestal with output on the short side (flat)
H362 vertical busbars (and support brackets with +H360) for DC output connection
H363 busbar kit for DC and brake outputs on different long sides of the pedestal (+H356
required, not available for +H360)
Control panel J400 control panel including a 3-metre panel connection cable
J410 RPMP-11 control panel mounting platform kit including a 3-metre panel connection
cable but no control panel
J413 RPMP-21 control panel holder
Fieldbus K... Refer to ACS800 Ordering Information (EN code: 64556568).
I/O L...
Control program N...
Language of manual R...
Specialities P901 coated boards
Safety features Q950 Prevention of Unexpected Start, 500 mm (19.68 in.) cable outside the drive module in
frame size R7, 600 mm (23.62 in.) cable outside the drive module in frame size R8.
