Mechanical installation of non-pre-assembled units (ACS800-04M)
45
Mechanical installation of non-pre-assembled units
(ACS800-04M)
What this chapter contains
This chapter describes how to assemble the drive from the assembly kits. First,
before-installation information is given, such as required tools, moving the unit and
checking the delivery. Then, the working order of the mechanical installation is
described. Thereafter, particular assembling instructions follow.
How to read this chapter
Units with bottom exit
1. Read sections Required tools and tightening torques and Moving and unpacking
the unit.
2. Go to section Frame size R7 units with bottom exit (+H352) on page 49.
Units with pedestal and busbars on the long side (+H354, bookshelf mounting)
1. Read sections Required tools and tightening torques and Moving and unpacking
the unit.
2. Identify your unit by its type code with the help of section Units with pedestal and
busbars on the long side (+H354, bookshelf mounting) on page 57.
3. Choose the applying instructions in section Assembling procedure for units with
busbars on the long side (+H354) on page 73.
Units with pedestal and busbars on the short side (+H360, flat mounting)
1. Read sections Required tools and tightening torques and Moving and unpacking
the unit.
2. Identify your unit by its type code with the help of section Units with pedestal and
busbars on the short side (+H360, flat mounting) on page 91.
3. Choose the applying instructions in section Assembling procedure for units with
busbars on the short side (+H360) on page 104.
