Mechanical installation of non-pre-assembled units (ACS800-04M)
65
Pedestal R8
+H354
64754424 Base mounting from outside:
Wall mounting:
Mounting bracket and grounding
terminal kit R8 (+H354)
64744330
Motor output busbar kit R8
+H355
64743295
ACS800-04M of frame size R8 with busbars on the long side
Package Parts Assembling instruction ProE code 64772023 E
Pedestal
Front
Front
PE terminals
Wall mounting bracket
Base mounting
brackets
left
right
AC output busbars
Motor cable terminals
Support brackets
Insulating
supports
Front
