EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 87
Magnos28: Changing the range limits
Menu path
Setup Measurement Ranges
The range limits can also be set in the configurator (see page 82).
NOTES
Measuring ranges must not be set within ignition limits.
The calibration of the measuring range should be checked after the range
limits have been changed.
Range limits
The start value of the measuring range and the end value of the measuring
range must be within the physical measuring range.
Setting range
The measuring ranges can be freely set within the limits of the physical
measuring range (see page 80).
The measuring ranges are set ex works to 0 to 25 % vol. of O
2
and 0 to
100 % vol. of O
2
or per order.
The smallest measuring range is 0 to 0.5 % vol. of O
2
. The smallest span of a
measuring range with a suppressed zero point is 1 % vol. of O
2
.
Physical measuring range
The analyzer has a physical measuring range. The limits of this measuring
range are 0 % vol. of O
2
and 100 % vol. of O
2
.
