ABB HVC User Manual

HVC 450 kW E-Bus Charger Installation Guide
Revision: 1.2 COMPANY CONFIDENTIAL
Date released: 16-08-2018 Page 113 of 128
8.3. Environment
Environment specification Power Cabinet
Ingression protection
IP54
Temperature range – Operation
-35 ºC to +45 ⁰C
Temperature range – Storage
-10 ºC to +70 ⁰C
Humidity
5 % to 95 %, RH – non-condensing
Airflow
51206.27 ft
3
/h
Pressure drop
300 pA
Altitude
6561.68 ft (max.)
Storage conditions
Indoors, dry
Environment specification ACS Control Module
Ingression protection
IP54
Temperature range – Operation
-35 ºC to +45 ⁰C
Temperature range – Storage
-10 ºC to +70 ⁰C
Humidity
5 % to 95 %, RH – non-condensing
Altitude
6561.68 ft (max.)
Storage conditions
Indoors, dry
Environment specification ABB Pole
Ingression protection
IP54
Temperature range – Operation
-35 ºC to +45 ⁰C
Temperature range – Storage
-10 ºC to +70 ⁰C
Humidity
5 % to 95 %, RH – non-condensing
Altitude
6561.68 ft (max.)
Maximum operational wind speed
44.7 mph (8 Bft)
Maximum deflection
89.5 mph (14 Bft)
Storage conditions
Indoors, dry
CAUTION
Warranty
Warranty will be considered void when the HVC 450 kW E-Bus Charger
is damaged while badly stored at the customer's location.
8.4. Certifications
Certifications for complete system
UL 2202
HVC 150: Certificate No. TU 72180445
Class of protection
1 with GND connection
