ABB IRB 6700 Series User Manual

Illustration 2
A
P
S
R
C
J
L
J
J
N
N
N
T
D
E
G
IllustrationDescription
Calibration labelA
xx0900000816
Instruction label
Before dismantling see product manual
B
45°
20°
70°
890 50
570 55
65°
!
!
!
4x
IRB 6700, m = 1160 - 1600 kg / 2557 - 3527 lbs
3HAC 046732-001 / 00
4x, 2000kg, 2,5 m
1x, 2000 kg, 2 m/2,5 m
1x, 2000 kg, 2 m
45°
20°
70°
890 50
570 55
65°
xx1300001084
Instruction label
Lifting of robot
C
Continues on next page
Product manual - IRB 6700 143
3HAC044266-001 Revision: N
© Copyright 2013 - 2018 ABB. All rights reserved.
3 Maintenance
3.3.10 Inspecting the information labels
Continued

ABB IRB 6700 Series Specifications

General

Payload	150-300 kg
Reach	2.60-3.20 m
Number of Axes	6
Protection Rating	IP67
Controller	IRC5
Protection	Foundry Plus 2
Mounting	Floor
