ABB IRB 6700 Series User Manual

4.8 Gearboxes
4.8.1 Replacing the axis-1 gearbox (IRB 6700 - 235/2.65, IRB 6700 - 205/2.80, IRB
6700 - 175/3.05, IRB 6700 - 150/3.20, IRB 6700 - 200/2.60, IRB 6700 - 155/2.85)
Validity of this section
Note
This section describes how to replace the gearbox on variants IRB 6700 - 235/2.65,
IRB 6700 - 205/2.80, IRB 6700 - 175/3.05, IRB 6700 - 150/3.20, IRB 6700 - 200/2.60,
IRB 6700 - 155/2.85.
How to replace the gearbox on variants IRB 6700 - 300/2.70, IRB 6700 - 245/3.00
see Replacing the axis-1 gearbox (IRB 6700 - 300/2.70, IRB 6700 - 245/3.00) on
page 626.
Location of the axis-1 gearbox
The axis-1 gearbox is located as shown in the figure.
xx1200001183
Continues on next page
586 Product manual - IRB 6700
3HAC044266-001 Revision: N
© Copyright 2013 - 2018 ABB. All rights reserved.
4 Repair
4.8.1 Replacing the axis-1 gearbox (IRB 6700 - 235/2.65, IRB 6700 - 205/2.80, IRB 6700 - 175/3.05, IRB
6700 - 150/3.20, IRB 6700 - 200/2.60, IRB 6700 - 155/2.85)

ABB IRB 6700 Series Specifications

General

Payload	150-300 kg
Reach	2.60-3.20 m
Number of Axes	6
Protection Rating	IP67
Controller	IRC5
Protection	Foundry Plus 2
Mounting	Floor
