Location of gearboxes

The figure shows the location of the gearboxes.

xx1400000189

Gearbox, axis 1A

Gearbox, axis 2B

Gearbox, axis 3C

Gearbox, axis 4D

Gearbox, axis 5E

Gearbox, axis 6F

Equipment

NoteEquipment

Includes pump with outlet pipe.Oil dispenser

Use the suggested dispenser or a similar one:

• Orion OriCan article number 22590

(pneumatic)

Nipple for quick connect fitting, with o-ring
