NoteAction

Screws: M10 quality 12.9.Apply flange sealant and refit the cover

plate on the back of the balancing device.

Tightening torque: 50 Nm.

Flange sealant for conical fittings: Loctite

577.

xx1300000554

DANGER

The rear cover of the balancing device is

a safety device for the piston rod during

operation! Make sure the cover is properly

secured before commissioning of the ro-

bot!

498 Product manual - IRB 6700

3HAC044266-001 Revision: N

4 Repair
