10 M4M 30 NETWORK ANALYZER USER MANUAL
3.5.Technical data
Auxiliary power supply
Voltage range [V] 48 to 240 VAC/VDC ±15%
Frequency [Hz] 50/60 Hz ±5%
Power Consumption [VA] 10 VA max
Installation category CAT III 300V class per IEC 61010-1 edition 3
Protection fuse T1 A - 277 VAC
Measurement accuracy*
Measurement type True RMS up to the 40th harmonic
128 samples per cycle, zero blind
IEC 61557-12 IEC 61557-12 PMD/S/K70/0,5
Active energy Class 0,5 acc. to IEC 61557-12
Class 0,5S acc. to IEC 62053-22
Reactive energy Class 2 acc. to IEC 61557-12
Class 2S acc. to IEC 62053-23
Active power Class 0,5 acc. to IEC 61557-12
Reactive power Class 1 acc. to IEC 61557-12
Apparent power Class 0,5 acc. to IEC 61557-12
Voltage Class 0,2 acc. to IEC 61557-12
Current Class 0,2 acc. to IEC 61557-12
Neutral current Class 0,2 acc. to IEC 61557-12
Frequency Class 0,1 acc. to IEC 61557-12
Unbalances Class 0,2 acc. to IEC 61557-12
Harmonics, THD (Current, voltage) Class 1 acc. to IEC 61557-12
*Accuracy referred to insertion with .../5A CT or Rogowski coils. Derating for .../1A CT.
Voltage measurement inputs
Measurement range [V] 50 - 400 VAC (L-N) 87 - 690 VAC (L-L)
Measurement category 400V~ (CAT III)
Rated frequency [Hz] 50-60 Hz
Max. VT secondary (indirect connection) [V] 400 VAC (L-N)
Max over voltage [V] 800 VAC (L-L)
Protection fuse T1 A - 277 VAC
Current measurement inputs
Number of current inputs 4 (L1, L2, L3, N)
Indirect insertion with CT
CT secondary 5 A (Class 0.5S)
1 A (Class 1)
Measurement range without accuracy derating 50 mA - 6 A
Starting current 5 mA
Burden 0.024 VA at 6 A
Indirect insertion with Rogowski coils (only M4M 30 Rogowski)
Rated current 10000 A
Measurement range without accuracy derating 100 A - 12 kA
Starting current 10 A
