8 M4M 30 NETWORK ANALYZER USER MANUAL
3.Technical characteristics
3.1.Description of the device
M4M 30 is ABB’s network analyzer range that allows complete power quality analysis and energy
efficiency evaluations.
All M4M 30 network analyzers are equipped with touchscreen color display for simplified access to the
device and with Bluetooth module for smart commissioning.
3.2.Main functionalities
Real-time
TRMS current •
TRMS Voltage •
Frequency •
Active, Reactive and Apparent Power •
Power Factor •
Operating timer, countdown timer •
Energy
Active, Reactive and Apparent Energy •
4 quadrant Energy (Import/Export) •
Tariffs •
Power quality
THD (I, VLN, VLL) •
Individual Harmonics 40th
Unbalances (I, VLN, VLL) •
Neutral current Measured
Phasors (I, VLN) •
Waveforms (I, VLN, VLL) •
Data recording and logs
Single alarms 25
Warnings, alarms and errors logs •
Complex alarms with logics 4
Demand values (average) Advanced
Min/Max Demand values Advanced
Energy Trending logs •
RTC •
HMI
Graphs visualization Advanced
Notifications •
Homepage and favourite page •
Password protection •
Connectivity
Automatic integration in ABB Ability™ EDCS •
Bluetooth Low Energy •
Communication Protocols
Modbus RTU, Modbus TCP/IP,
Profibus DP-V0, BACnet/IP
RJ45 Daisy Chain (Ethernet version) •
