76 M4M 30 NETWORK ANALYZER USER MANUAL
10.1.Realtime
Bargraphs showing in an intuitive way the realtime values of voltage, current and power. The graphs are
automatically scaled according to the values that are measured in realtime.
→ → Realtime
Graph
Line-Neutral voltage
Line-Line voltage
Current
Active Power
Reactive Power
Apparent Power
