Menu levels
There are three menu levels below the process display.
Process display
Information level Operating mode
Diagnosis Auto Adjust
Operator Page 1 Adaptive
Signals View Control
Manual SP
Manual Sensor
Configuration
Configuration
Easy Setup
Device Setup
Display
Control
Input/Output
Communication
Diagnosis
Device Info
Service
Change from one to tw o columns
Process display
The process display shows the current process values.
Information level
The information level contains the parameters and information
that are relevant for the operator. The device configuration
cannot be changed on this level.
Operating modes menu
In the operating modes menu, the Auto Adjust function can be
started for commissioning purposes. You can also change the
operating modes and switch to the configuration level.
Configuration level
The configuration-, parameterization instruction contains all the
parameters required for device commissioning and
configuration. The device configuration can be changed on this
level.
NOTICE
Property damage
During external configuration via a PC, the positioner no
longer responds to the set point current. This may lead to
process failures.
• Before any external parameterization, always move the
actuator to the safety position and activate manual
adjustment.
Note
For a detailed description of the individual parameters and
menus on the configuration level, please refer to Parameter
descriptions on page 50.
