62 PositionMaster EDP300 DIGITAL POSITIONER | OI/EDP300-EN REV. D
… 9 Operation
… Parameter descriptions
Menu: Input/Output
Menu / parameter Value range Description
Input/Output
Digital Input DI Function
DI Default SP
DI Logic
Selection of functions or states that are executed or adopted if the ‘digital input’ has been activated.
Alarm Output Alarm Logic
DO Alarm Mask
Alarm Simulation
Use this parameter to configure the alarm output via which a general alarm can be issued. Depending on
the activated Namur classification group, it is also possible for the general alarm to be issued as an
alarm current.
Analog Feedback Analog Out Min.
Analog Out Max.
Feedbk. Charact.
AO Alarm Mask
AO Simulation
The current valve position (or when the ‘backward-calculated characteristics of the valve influence’) is
reported back as a current signal via the analog feedback message.
Depending on the activated Namur classification group, it is also possible for the general alarm to be
issued as an alarm current.
Digital Feedback Switch 1
SW 1 Mask Map
Switch 2
SW 2 Mask Map
Binary feedback can be used to configure two limit switches which are able to report when a value is
reached or exceeded, via a current signal. Additionally, diagnostics bits can be output via the second
switch.
Universal input UI SP Value Max.
UI SP Value Min.
UI Damping
UI Charact.
UI Out Value Max
UI Out Value Min
Use this menu item to configure and simulate the universal input.
